Every aspect of this moving floor trailer is extreme!

The ultimate, safe alternative to the large volume scrap tipper. The moving floor trailer is ideal for transporting heavily abrasive materials, such as scrap, rubble and bulky waste, including end-of-life vehicles, bulky building rubble, electric motors and engine blocks.

Completely self-supporting construction

The moving floor trailer is built on a self-supporting chassis made from High Strength Steel. The EXTREME has a generous load volume and, thanks to the self-supporting construction, weighs in at more than 330 kg lighter than the alternatives on the market.

Steel body
High volume, relatively low own weight
Steel rear doors
No rear upper beam
Clean Sweep mechanism

Rottne H8D

Extreme rear

The EXTREME moving floor trailer is equipped with steel rear doors and does not feature an upper beam at the rear. This enables heavy material to be loaded through the rear doors if required Instead of a protection plate, the trailer features a new foldable rear light plate. This can be operated using the unique Knapen Trailers remote control. A variety of options are possible.

Heavy duty moving floors

Depending on the type of load, the EXTREME can be equipped with various types of Heavy Duty moving floors. For example, we offer wear-resistant moving floors, but also impact-resistant floors. We have a moving floor available to suit every type of material.

The benefits of the EXTREME:

Steel body
High volume, relatively low own weight
Completely self-supporting construction
Steel rear doors
No rear upper beam
Unique Knapen Trailers remote control
Foldable light beam
Clean Sweep mechanism
LED work lighting
Various types of HD moving floors possible

Basic specifications

	Standard
Length	13,67 m
Height	4,0 m
width	2,55 m
Volume	88 m³
Fifth wheel height	1,15 m
Wheelbase	7,75 m
Number of axles	3
Max. Axle load	27 ton
Max. Fifth wheel load	18 ton
