12MD | MDH



Kesla’s 12-series timber trailers have been designed for professional use with even the largest tractors.

These trailers are available whether with mechanical or hydrostatic-mechanical drive. Their terrain-operating characteristics are exceptional, and the line includes timber trailers with traction capacity of up to 5 tonnes. In difficult conditions, the terrain ability can be improved with chains or tracks. Drive release facilitates faster driving speed in highway traffic.
The mechanical 12MD/MDH trailer can be fitted with hydraulically controlled head rack, frame lock and a rear-axle mounted tow bar.

MODEL PRODUCT FAMILY () CARRYING CAPACITY (t) WEIGHT INCLUDING FRONT SCREEN, BEAM CONTROL AND EXTRA BUNK (kg) TOTAL LENGTH (mm) TOTAL WIDTH (mm) LOAD SPACE AREA (m2) LOAD SPACE LENGTH (mm) GROUND CLEARANCE (mm)
KESLA12MD 12 12 3220 6210 2250-2500 3.15 4050 530-560
KESLA12MDH 12 12 3700 6210 2250-2500 3.15 4050 530-560
