CLARK Renegade (S25-35XE) – these are electric "crossover" forklifts that redefine the standards for modern forklift trucks. These powerful and quietly operating electric forklifts combine advanced Li-ion technology with a robust, ergonomically optimized frame, ideally suited for both indoor and outdoor applications. Their emission-free and low-noise operation makes the "Renegade" an excellent choice for mixed work areas where quiet processes are a key advantage.

WHY CHOOSE CLARK Renegade (S25-35XE)?

CLARK "Crossover" Renegade (S25-35XE) models combine the best features: their dimensions and functionality match those of diesel and LPG forklifts, providing the same performance and robustness expected from internal combustion engine-powered models. At the same time, enjoy all the benefits of a modern, emission-free electric drive. This unique combination of power, flexibility, and environmental friendliness allows the "CLARK Renegade (S25-35XE)" to set new standards for various applications – both indoors and outdoors.

Maximum visibility and safety:

• Good All-Round Visibility: Proven, interlocking mast profiles ensure a robust design and a narrow "column" to maximize visibility.

• CLARK SMART Dashboard: The intuitive dashboard allows for easy operation of the "CLARK Renegade (S25-35XE)". Operator instructions are available in several languages. The display can optionally show the load weight or the image from the reversing camera.

• Maximum Safety with Operator Presence System (OPS) as standard: The "CLARK Renegade (S25-35XE)" comes standard with an Operator Presence System (OPS), which significantly increases the safety of the operator and their surroundings. This system monitors the driver's presence and automatically switches off hydraulic and driving functions as soon as the driver leaves the seat. This prevents unintentional truck movements and provides additional protection against accidents and injuries. The OPS ensures that the truck remains active only when the driver is safely seated and in control.

Top-class ergonomics and comfortable operation:

• Ergonomic Hydraulic Levers: Ergonomically located hydraulic levers next to the driver's seat, with integrated directional control on the hydraulic lever, allow for intuitive and effortless maneuvering.

• Excellent Headroom: The overhead guard provides generous headroom, significantly increasing both operator comfort and safety.

• Indoor and Outdoor Use: Thanks to water-protected components, such as IP54 protection (dust and splash-proof) for the drive and hydraulic motors, the forklift can be used outdoors without problems, even in bad weather.

• Easy Access to the Battery: The bonnet can be opened wide to check the battery and facilitate access to the truck interior.

• Cabin Program: In the full cabin, the two-part driver's doors can be opened 180° and attached to the vehicle frame. This allows driving with the door open, for example, in summer. A standard heated rear window, easily accessible storage compartments, and a Bluetooth-enabled radio complement the comfortable full cabin. Another advantage is that the full cabin can be entered and exited from both sides of the vehicle. This makes the driver's daily work easier in many situations.

CLARK Lithium-ion technology:

• Flexible Energy Supply with safe Lithium-Ion Batteries: Batteries with capacities of 205 Ah, 410 Ah, and 460 Ah are offered. All batteries are based on safe lithium iron phosphate technology (LiFePO4), which is characterized by a high level of safety and durability. Various chargers are also available, including an onboard charger integrated into the truck, which allows for fast and flexible recharging anytime and anywhere – both indoors and outdoors. Long operating times and short charging cycles make the "Renegade" a reliable partner for companies that do not want to compromise between performance and sustainability.

OPTIONAL EQUIPMENT:

• Blue LED Warning Lights: Blue LED warning lights provide a visual warning for both directions of travel.

• Fork Positioners with Sideshift: CLARK fork positioners are ideal for changing load widths and increase handling capacity. Includes separate sideshift function.

• Full Cabin with Air Conditioning: For increased productivity on hot days. Features good cooling performance, dehumidification, and integrated cooling and heating functions.

• CLARK VMS System: When this function is activated, the mast's tilting process automatically stops in the vertical position when tilting forwards or backward.

• Load Weight Indication: The load weight indicator ensures accurate weight readings, even when different attachments are in use. This is made possible by a driver-activated tare function.

• Integrated Charger: The integrated charger with 80 V and 35 Ah allows flexible charging from any conventional 230 V socket.

• Driver's Seats: The driver's seat is available with either mechanical suspension or air suspension. Various versions are offered with an orange seat belt, side safety bars, or armrests.

• Hydraulic Levers: Control levers mounted on the bonnet come as standard, with an option for up to five hydraulic functions to support various attachments.

• Armrest with Integrated Mini Levers: Ergonomic mini levers for hydraulic control are available, with the option to integrate the travel direction change into the armrest upon request.

• Direction Switch on the Hydraulic Lever: Switching the direction of travel directly on the hydraulic lever reduces the driver's workload by eliminating the need to reach around the steering column to change direction.

• Reversing Camera: Enhanced safety during operation thanks to a wide field of vision for activities behind the truck, provided by a rear-mounted camera.

• Storage Compartment: Available with a USB charging port.

TECHNICAL SPECIFICATIONS:

Model	S25XE	S30XE	S35XE
Load capacity in kg	2500	3000	3500
Overhead guard heights mm	2165	2180	2200
Total width mm	1190	1225	1278
Lifting height from/to mm	2120/7315	2120/7315	2120/7315
Working aisle width with pallet 800 x 1200 along (mm)	4135	4195	4255
Driving speed with/without load (km/h)	18/18	18/18	18/18
Battery voltage/ max. rated capacity	80 V, 410	80 V, 460	80 V, 460

The CLARK Renegade (S25-35XE) – an intelligent choice for sustainable future work with top performance.

Interested? Contact us, and we'll help you choose the CLARK Renegade (S25-35XE) model that best suits your needs!
